TM304R Toddler Playground Climbing Frame

Product Code: TM304R

A long-format toddler play tower with three decks, a blue brick-pattern roof, wooden plank bridge, yellow cutout activity panels and one-piece stainless steel slide. The TM304R brings 0.3m, 0.57m and 0.9m decks into a 3.47m x 4.40m footprint for narrow nursery gardens. Made in Yorkshire to BS EN1176.

Manufactured in-house at our Yorkshire facility
Heavy-duty fully welded steel construction
Customisable Colours

Download Spec

Categories: Playground Equipment, Climbing Frames

Durable, customisable, made to last

TM304R Toddler Playground Climbing Frame

Designed and manufactured in the UK to meet EN1176 standards, our Toddler Multi-Play System offers a durable, low-maintenance solution for any playground. Built from heavy-duty steel with a galvanised and powder-coated finish, it’s made to withstand years of active play while maintaining its appearance. With a variety of play elements to encourage climbing, balance, and exploration, it’s an ideal choice for schools, parks, and community spaces. Check out the specification sheet or the York Play Products range to see what makes our play units stand out.

Materials

88.9mm Ø x 3mm steel uprights with welded dome caps
Fully welded or sleeved component construction throughout
One-piece pressed stainless steel slide, fully welded
Threaded inserts with Torx head security stainless steel fixings (tamper-resistant)
Shot blast (SA 2.5) preparation, PZ 770 zinc-rich primer, powder-coated topcoat in a choice of colours

Product code: TM304R
Overall dimensions (L x W x H): 3.47m x 4.40m x 2.61m
Deck heights: 0.3m, 0.57m and 0.9m
Free height of fall: 0.9m
Minimum space required (L x W): 6.47m x 7.40m
Impact area (1m x 1m tiles): 49
Impact area (wetpour): 43.5m²
Concrete pin kerbs (tiles/wetpour): 28.5 linear metres
Heaviest part: 31kg
Largest part: 3.05m (roof upright)
Compliance: BS EN1176

Technical Details

Every York Play climbing frame is designed and manufactured in the UK from heavy-gauge steel that can be repaired, re-coated and ultimately recycled. Specifying robust, locally made playground equipment reduces the carbon and waste cost of premature replacement and avoids the transport footprint of imported alternatives.

Sustainability

Proven Delivery

Examples of Our Installations

A selection of recent projects that demonstrate our experience delivering reliable, long-lasting facilities. Each installation is shaped by site constraints, client requirements, and real-world use.

Your Questions Answered

Frequently Asked Questions

We’ve answered some of the most frequently asked questions below to help you understand specifications, lead times, installation, and what to expect at each stage.

Don’t see your question? Get in touch and we would be happy to help.

Ask us a question

What's the best outdoor play equipment for schools?

For most schools, the most cost-effective outdoor play equipment is a single multi-play playground climbing frame as the focal point of the playground, supplemented by separate agility, swing and free-play items. For EYFS and nursery use, our Toddler Playground Climbing Frame range offers age-appropriate equivalents. All our outdoor play equipment is UK-made and certified to BS EN1176.

Are powder-coated steel climbing frames better than painted or wooden ones?

Powder coating is more durable than wet paint for outdoor playground equipment. Powder is applied dry and cured under heat, forming a thicker, harder and more impact-resistant surface that resists chips, scratches and weathering. Compared to timber, powder-coated steel does not rot, warp, splinter or need ongoing re-staining, giving a longer service life and a lower whole-life cost.

Can climbing frames be installed on grass?

A climbing frame can sit close to grass, but the area directly under and around the equipment (the impact area) must be surfaced with a critical-fall-rated impact surface such as wetpour or rubber tiles, retained by concrete pin kerbs. Grass alone is not classified as an impact-absorbing surface under BS EN1177.

How big is the TM304R and how much space does it need?

The TM304R itself measures 3.47m x 4.40m x 2.61m. You should allow a minimum installation footprint of 6.47m x 7.40m to accommodate the surrounding safety zone, plus access room for children to queue and enter the frame safely.

What surfacing do I need underneath the TM304R?

With a free height of fall of 0.9m, the TM304R needs a critical-fall-rated impact surface across its full impact area. That works out at 49 one-metre-square rubber tiles or 43.5m² of wetpour, retained with 28.5 linear metres of concrete pin kerbs.
